features >

• 3 phono, 5 line, & 2 mic inputs
• Separate bass/treble for each channel
• Balanced XLR outputs
• Bass/treble control for DJ mic
• On/off/talkover switch for DJ mic with Neutrikª connection - 1/4”(6.3mm)/XLR
• Left & right turntable ground connectors
• High quality Feather Faderª for smooth, clean crossfading (replaceable/made in Japan)
• On/off switch for channel assign
• Accurate beat LEDÕs for easy crossfades
• Master & booth/zone volume control
• Cue mixing/cue level controls
• Stereo/mono switchable
• Left/right balance control
• 7-Band graphic equalizer w/ on/off
• Master level LED display w/ peak hold
• High level headphone output
• 12V BNC light connector for gooseneck light XDM-352 Specificat2ions:
• Line Output: 20V peak to peak, (+20dB)
• S/N Ratio: Line= >80dB
• Channel EQ: -30dB - +20dB for bass, mid & treble
• Frequency Range: 20Hz - 20kHz, +/-1dB
• Talkover: -15dB
• Headphone Impedance: 16 Ohms
• Power: 110V/220V switchable
• Crossfader: FF-2
• Dimensions: 19" W x 9.5" D x 3.25" H - 482mm x 242mm x 82.5mm
• Weight: 12 lbs. / 4.5 kg.
